The 2026 Harley-Davidson® Street Glide® Limited is engineered as a full-scale touring motorcycle with a focus on mechanical performance, integrated systems, and long-distance functionality. The model uses a Milwaukee-Eight® VVT 117 engine, a six-speed transmission, and a belt-driven final drive. Its structure includes a steel frame, advanced suspension components, and a high-capacity electrical system. The motorcycle also incorporates a complete infotainment platform, multiple electronic rider aids, and a defined set of physical dimensions that support highway stability and load management.
Engine Configuration and Output Specifications
The 2026 Harley-Davidson® Street Glide® Limited uses a Milwaukee-Eight® VVT 117 engine with a displacement of 117 cubic inches, equivalent to 1,923 cubic centimeters. The engine features a pushrod-operated overhead valve configuration with four valves per cylinder and hydraulic, self-adjusting lifters. Bore measures 4.075 inches, while stroke measures 4.5 inches. The compression ratio is rated at 10.3:1.
Fuel delivery is handled through Electronic Sequential Port Fuel Injection, which supports controlled fuel distribution and combustion efficiency. The air intake system uses a washable fiberglass air cleaner. Exhaust flow is managed through a 2-1-2 dual exhaust system with tapered mufflers. Lubrication is maintained through a pressurized dry-sump system.
The engine produces 131 foot-pounds of torque at 3,250 revolutions per minute. Power output is rated at 106 horsepower at 4,600 revolutions per minute. These figures reflect the engine’s emphasis on low and mid-range torque delivery. The configuration supports acceleration under load and sustained cruising at highway speeds without requiring high engine speed.
Drivetrain Architecture and Gear Ratios
Power from the engine is transferred through a chain-driven primary system with a 34/46 ratio. Final drive uses a belt system with a 32/68 ratio. The clutch is a mechanically actuated 10-plate wet design with assist and slip functionality. This configuration reduces lever effort and helps manage rear-wheel engagement during downshifting.
The transmission is a 6-Speed Cruise Drive® system. Gear ratios are distributed as follows: first gear at 9.593, second gear at 6.65, third gear at 4.938, fourth gear at 4.0, fifth gear at 3.407, and sixth gear at 2.875. This spread allows controlled launch characteristics in lower gears and reduced engine speed in higher gears during cruising. The drivetrain is configured to maintain steady output across different riding conditions, including loaded touring scenarios.
Structural Dimensions and Load Capacity
The motorcycle measures 103.3 inches in overall length, 40.7 inches in width, and 56.7 inches in height. The wheelbase is set at 64 inches. Steering geometry includes a rake of 26 degrees, a fork angle of 29.25 degrees, and a trail measurement of 6.7 inches. These values define steering stability and directional control.
Seat height is 27.5 inches when laden and 29.1 inches when unladen. Static ground clearance is 5.9 inches. These measurements support low-speed maneuverability while maintaining sufficient clearance for cornering angles.
The weight of the motorcycle is 855 pounds as shipped and 893 pounds in running order. Gross Vehicle Weight Rating is 1,360 pounds. The front axle is rated at 500 pounds, and the rear axle at 927 pounds. These figures define the maximum supported load, including rider, passenger, and cargo.
Fuel Capacity and Fluid Management
Fuel capacity is rated at 6 gallons, with a 1-gallon reserve indicated by a warning system. Estimated fuel economy is 45 miles per gallon. This capacity supports extended travel distances between refueling intervals.
Engine oil capacity with filter is 5 quarts. The transmission requires 1 quart of fluid. The primary chain case holds 1.1 quarts. Coolant capacity is 0.82 quarts. These values define the fluid requirements for operation and maintenance.
Luggage capacity measures 5.05 cubic feet. This volume is integrated into the touring structure and supports storage for extended travel. The available space accommodates cargo without altering the motorcycle’s balance or structural integrity.
Chassis Construction and Suspension Systems
The frame is constructed from mild steel using a tubular structure with a two-piece stamped and welded backbone. It incorporates cast and forged junctions, twin downtubes, and a bolt-on rear frame with forged fender supports. Welding is completed using MIG processes. The swingarm is also made of mild steel with a two-piece drawn and welded structure and forged junctions.
Front suspension uses a 49 millimeter Dual Bending Valve fork with 4.6 inches of travel. Rear suspension consists of dual adjustable emulsion shocks with 3 inches of travel. The left rear shock includes remote preload adjustment, while the right shock uses threaded preload adjustment. These adjustments allow compensation for varying load conditions and rider preference.
Wheel construction uses cast aluminum components. The front wheel measures 19 inches in diameter and 3.5 inches in width. The rear wheel measures 18 inches in diameter and 5 inches in width. Tires are specified as Dunlop® Harley-Davidson® Series, with a 130/60B19 front tire and a 180/55B18 rear tire. This configuration supports traction, load distribution, and stability.
Braking System and Mechanical Control
The braking system includes dual floating rotors on the front and a fixed rotor on the rear. The front brake diameter measures 12.6 inches with a thickness of 0.18 inches. Rear brake diameter measures 11.8 inches with a thickness of 0.28 inches.
Front calipers are 32 millimeter four-piston fixed units mounted axially. The rear uses a single axially mounted caliper. The front braking system is dual-disc, providing increased stopping force. An Anti-lock Braking System is included as standard equipment.
Electronic Rider Safety Enhancements
The 2026 Harley-Davidson® Street Glide® Limited integrates a range of electronic systems to assist with rider control. Anti-lock Braking System is standard. Electronic Linked Braking is included to distribute braking force between the front and rear wheels. The Traction Control System is also standard and manages rear-wheel traction during acceleration.
Drag-Torque Slip Control System reduces the effect of engine braking during aggressive downshifts. Vehicle Hold Control assists with maintaining position on inclines during stops. The Tire Pressure Monitoring System provides continuous monitoring of tire pressure levels.
The motorcycle also includes cornering-enhanced systems. These consist of Cornering Enhanced Anti-lock Braking System, Cornering Enhanced Electronic Linked Braking, Cornering Enhanced Traction Control System, and Cornering Drag-Torque Slip Control System. These systems adjust performance based on lean angle and vehicle dynamics.
Electrical System and Lighting Components
The electrical system includes a sealed, maintenance-free 12-volt battery rated at 28 amp-hours and 405 cold cranking amps. Charging is provided by a three-phase system rated at 58 amps, delivering up to 754 watts at 13 volts. Starting is managed by a 1.6-kilowatt electric starter with solenoid engagement.
Lighting systems use LED technology for the headlamp, tail and stop lights, front signal lights, and rear turn signals. Auxiliary LED fog lamps are integrated into the lower fairings. These components support visibility and durability.
A digital gauge system is integrated into the display, providing key operational data. Additional information includes air temperature, oil pressure, and engine idle temperature management system indicators. Power access is provided through a 15-watt USB-C port located in the media storage compartment and an additional power port in the Tour-Pak®.
Infotainment System and Connectivity Interface
The infotainment system operates on Skyline™ OS and uses a 12.3-inch full-color TFT display. The interface integrates vehicle data, navigation, and media controls. Audio output is delivered through four speakers, each supported by 50 watts per channel. The system includes two 6.5-inch speakers in the fairing and two 6.5-inch speakers in the Tour-Pak®.
Standard audio functionality includes AM and FM radio. Media playback is supported through USB connections, including SD cards, flash drives, and MP3 formats. Bluetooth® connectivity enables hands-free phone operation and media streaming. The system also supports headset connectivity for rider and passenger communication.
Apple CarPlay® compatibility is included in both wired and wireless formats. Navigation is embedded within the system and provides route guidance along with traffic and weather data through a Wi-Fi hotspot connection. The display consolidates operational and infotainment data into a single interface.
